SATCO NUVO's High Lumen and CCT Selectable PAR lamps are designed for diverse indoor and outdoor applications. With crisp, 90 CRI light output choose 2700K/3000K/3500K/4000K/5000K color temperatures at installation to create the perfect atmosphere. Offered in 120V and 120V-277V range voltage, they are an ideal lamp for residential, commercial, hospitality, general lighting, recessed downlighting and task lighting. And, with a wet location rating, these lamps are also perfect for use outdoors in flood lighting and landscape lighting uses.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S32250 |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S32250_Dimensional_Diagram.pdf |
| Lighting Type | Lamps |
| Fixture Type | PAR |
| Tariff Code | 8539.52.0030 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | California T24 Listed |
| Housing Color | Silver |
| CBCP | 3272 |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus |
| Location Rating | Wet |
| Indoor Outdoor | Indoor/Outdoor |
| Amps | 0.280A |
| ANSI Base | E26 |
| Beam Spread | 40° |
| Burning Position | Universal |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Dimming Technology | 120V |
| Avg Rated Hours | 25000 |
| Incandescent Equiv | 250W |
| Base | Medium |
| Lamp Filament | LED |
| Shape | PAR38 |
| Brightness (Lumens) | 3000 |
| Voltage | 120 |
| Wattage | 21 |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Plastic |
| Finish | Silver |
| THD | 8.53% |
| Lensed | Yes |
| Lens Finish | Frost |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.9 |
| Three-Way | No |
| MOD | 4.76" |
| MOL | 5.12" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0759 |
| Pack Type | Color Box |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 6 |
| Inner Length | 15.16" |
| Inner Width | 10.24" |
| Inner Height | 5.91" |
| Inner Weight | 4 |
| Inner Cubic Ft. | 0.5309 |
| Case UPC | 10045900000000 |
| Case Quantity | 12 |
| Case Length | 21.06" |
| Case Width | 15.75" |
| Case Height | 6.69" |
| Case Weight | 9.35 |
| Case Cubic Ft. | 1.2842 |
| Catalog Description | 21 Watt PAR38 High Lumen LED - 27K/30K/35K/40K/50K CCT Selectable - Medium Base - 120 Volt |
| Description | 21PAR38/5CCT/HL/120V/D |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Dimmable Function | 120V Only |
| Image File Name | S32250.jpg |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 4.88 |
| Each Width In. | 4.88 |
| Each Height In. | 5.51 |
| Each Weight Lb. | 0.6 |
| Replaces | S22250 |
| Replaces | S22251 |
| Replaces | S22252 |
| Replaces | S22253 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | IPE04-1L |
| Dimmers | 66ELV |
| Dimmers | DSE06-10Z |
| Dimmers | VPE06-1LZ |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | DVCL-253P |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | 86/103 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | RRD-10D |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | 66DF-10W |
| Dimmers | DSL06 |
| Dimmers | DDL06 |
| Dimmers | MAELV-600 |
| Dimmers | SLV-600P |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DL6HD |
| Dimmers | DZ6HD |
| Dimmers | DUL06P-C2 |
| Dimmers | VSUL06D |
| Dimmers | RHCL450PTC |
| Dimmers | RH703PTUTC |
| Dimmers | WWRL50WH |
| Dimmers | REL06-WW |
| Dimmers | WSX-PDT-WH |
| Dimmers | RF9640-ND |
| Dimmers | SAL06P |
| Dimmers | ADTP703TU |
| Dimmers | DAL06P-C2 |
| Dimmers | SUF7 |
| Dimmers | NXFRD-UNV |
| Dimmers | S11270 |
| Dimmers | 80/2699 |
| Dimmers | 80/2700 |
| Dimmers | 80/2701 |
| Dimmers | 80/2702 |
| Dimmers | 80/2703 |
| Dimmers | 80/2704 |
| Dimmers | PD-3PCL |
| Dimmers | MRF2-3LD |
| Dimmers | MRF2-3PD |
| Dimmers | RRD-3LD |
| Dimmers | RRD-3PD |
| Dimmers | HQR-3LD |
| Dimmers | HQR-3PD |
| Dimmers | PHPM-WBX-120 |
| Dimmers | ODMR0205 |
| Dimmers | MR42400PLS |
| Dimmers | 87/204 |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;DSE06-10Z;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL-153P;LECL-153P;TTC |
| Company | SATCO |
| Status | Active |
| Product Name | 21W PAR38 High Lumens LED CCT Selectable Medium 120V |
