SATCO NUVO's Fire Rated Directional Downlights are the perfect solution to increase safety and offer focused light. Designed to provide exceptional illumination, these downlights also provide two hours of protection in the event of a fire, Improve illumination and peace of mind in residential, multi-family and commercial applications.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S11880 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S11880_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S11880_Dimensional_Diagram.pdf |
| Lighting Type | Fixtures |
| Fixture Type | Remote Driver LED Downlight |
| Fixture Shape | Round |
| Tariff Code | 9405.11.8010 |
| Warranty | 5 Years |
| Country of Origin | Vietnam |
| CA Web Text | California T24 Listed |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Wet |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 36° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 50W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 650 |
| Voltage | 120 |
| Wattage | 9 |
| Bulbs | 1 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Aluminum |
| Style | Utility |
| Finish | White |
| THD | <30% |
| Lens Finish | Frost |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | >0.9 |
| Surge Protection | Built-In Surge Protection - 1.5KV |
| Air Tight | Yes |
| Can Size | 4" |
| Ceiling Aperture | 4.25" Cutout |
| Connection | Direct Wired |
| Has Driver | Yes |
| IC Rated | Yes |
| Max Dry Wall Thickness | 1" |
| Mounting Type | Ceiling |
| Rec Spacing Between Fixtures | 3 ft. to 4 ft. |
| Sloped Ceiling Compatible | Yes |
| Trim Color | White |
| Diameter | 4.92" |
| Dimensions | H: 1.42" x DIA: 4.92" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0484 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 12 |
| Case Length | 11.02" |
| Case Width | 10.24" |
| Case Height | 11.02" |
| Case Weight | 15.21 |
| Case Cubic Ft. | 0.7196 |
| Catalog Description | 9 Watt LED - Fire Rated - 4 Inch Direct Wire Directional Downlight - Round Shape - White Finish - CCT Selectable - Dimmable - 120 Volts |
| Description | 9WLED/DW-FR/4/CCT-SEL/RND/DIR |
| Finish Family | White |
| DLC Approved | No |
| ENERGY STAR | No |
| UNSPSC | 39111515 |
| Image File Name | S11880.jpg |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 5.16 |
| Each Width In. | 3.19 |
| Each Height In. | 5.08 |
| Each Weight Lb. | 1.2 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | IPE04-1L |
| Dimmers | 66ELV |
| Dimmers | DSE06-10Z |
| Dimmers | VPE06-1LZ |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | DVCL-253P |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | 86/103 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | RRD-10D |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | DSL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | 66DF-10W |
| Dimmers | DDL06 |
| Dimmers | MAELV-600 |
| Dimmers | SLV-600P |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DL6HD |
| Dimmers | DZ6HD |
| Dimmers | DUL06P-C2 |
| Dimmers | VSUL06D |
| Dimmers | RHCL450PTC |
| Dimmers | RH703PTUTC |
| Dimmers | WWRL50WH |
| Dimmers | REL06-WW |
| Dimmers | WSX-PDT-WH |
| Dimmers | RF9640-ND |
| Dimmers | SAL06P |
| Dimmers | ADTP703TU |
| Dimmers | DAL06P-C2 |
| Dimmers | SUF7 |
| Dimmers | NXFRD-UNV |
| Dimmers | S11270 |
| Dimmers | 80/2699 |
| Dimmers | 80/2700 |
| Dimmers | 80/2701 |
| Dimmers | 80/2702 |
| Dimmers | 80/2703 |
| Dimmers | 80/2704 |
| Dimmers | PD-3PCL |
| Dimmers | MRF2-3LD |
| Dimmers | MRF2-3PD |
| Dimmers | RRD-3LD |
| Dimmers | RRD-3PD |
| Dimmers | HQR-3LD |
| Dimmers | HQR-3PD |
| Dimmers | PHPM-WBX-120 |
| Dimmers | ODMR0205 |
| Dimmers | MR42400PLS |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;DSE06-10Z;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL-153P;LECL-153P;TTC |
| Bulb Count | 1 |
| UL Application | Covered Ceiling Mount |
| Voltage Text | AC Only |
| Accessories | 80-943 |
| Accessories | 80-946 |
| Accessories | 80-950 |
| Accessories | 80-973 |
| Accessories | 80-985 |
| Accessories | S8000 |
| Accessories | S8002 |
| Accessories | 80-987 |
| Accessories | 80-867 |
| Accessories | 80-865 |
| Accessories | 80-997 |
| Clearance Height | 3 |
| Company | SATCO |
| Status | Active |
| Product Name | 9W LED Fire Rated 4" Direct Wire Downlight Round White |
