Satco's new high bay/low bay offers improved performance on every level and are now power selectable to cover a wider range of applications. Replaces 175 to 600 Watt HID technologies using 60 to 150 Watts of efficient, superior LED light. The redesigned compact shape expands fixture compatibility options, and advanced heat dissipation design featuring convection cooling means a cooler running, longer lasting lamp. Commercial venues everywhere have been relying on these fixtures for years such as warehouses, gymnasiums, health clubs, factories and arenas - everywhere superior light output is critical and reducing maintenance is important.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S33115 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S33115_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S33115_Dimensional_Diagram.pdf |
| Collection | Hi-Pro |
| Lighting Type | Lamps |
| Fixture Type | LED HID |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | Malaysia |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor/Outdoor |
| IP Rating | IP64 |
| Amps | 0.800-0.289/1.000-0.361/1.300-0.469A |
| ANSI Base | EX39 |
| Ballast Bypass Direct | Ballast Bypass |
| Beam Spread | 120° |
| Burning Position | Universal |
| CCT Selectable | No |
| Color of Light | Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | No |
| HID Equiv | 250W/320W/400W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 400W |
| Base | Mogul Extended |
| Lamp Filament | LED |
| Shape | Corncob |
| Lamp Ballast Type | Type B |
| Brightness (Lumens) | 11200/14000/18200 |
| Voltage | 120-277 |
| Wattage | 80/100/130 |
| Color Temperature (Kelvin) | 5000K |
| Material | Aluminum / Plastic |
| Finish | White |
| Operating Frequency | 50/60Hz |
| Operating Temp | -25C (-13F) to +50C (+122F) |
| Power Factor | 0.99 |
| Surge Protection | Built-In Surge Protection - 4KV |
| Three-Way | Yes |
| MOD | 5.51" |
| MOL | 9.72" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.2371 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923331159 |
| Case Quantity | 6 |
| Case Length | 18.31" |
| Case Width | 12.4" |
| Case Height | 12.52" |
| Case Weight | 24.27 |
| Case Cubic Ft. | 1.645 |
| Catalog Description | 80/100/130 Wattage Selectable - LED - Hi-Bay - Type B - Ballast Bypass - Mogul Extended - 5000K - 100V-277V - 250W-400W Metal Halide Replacement |
| Description | 130W/LED/HID-HB/5K/100-277V |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Ballasting Requirements | Ballast Bypass |
| Enclosure Rating | Both |
| Image File Name | S33115.jpg |
| Installation Notes | Not for use in vapor tight fixtures. |
| Minimum Compartment Size | Length: 15.75 in. Width: 14.96 in. |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 5.91 |
| Each Width In. | 5.91 |
| Each Height In. | 11.73 |
| Each Weight Lb. | 2.94 |
| Replaces | S13115 |
| Replaces | S23115 |
| Replaces | S13153 |
| Company | SATCO |
| Status | Active |
| Product Name | 80/100/130W Selectable LED Hi-Bay Base Type B Ballast Bypass |
