Designed to deliver impressive brightness, LED High Lumen PL Lamps outshine traditional fluorescents. The G24d base allows for seamless replacement of outdated fixtures, providing a hassle-free upgrade. With their advanced ballast bypass Type B technology, compatibility concerns are a thing of the past. Enjoy uniform illumination with a wide 300 degree beam angle, ensuring comprehensive coverage in any space. These lamps are engineered to withstand damp environments, making them ideal for various applications. Plus, they are rated for enclosed fixtures, ensuring optimal performance and safety.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S21413 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S21413_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S21413_Dimensional_Diagram.pdf |
| Lighting Type | Lamps |
| Fixture Type | PL 2-Pin |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cRUus, cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor/Outdoor |
| Amps | 0.117/0.051A |
| ANSI Base | G24d |
| Ballast Bypass Direct | Ballast Bypass |
| Beam Spread | 300° |
| Burning Position | Universal |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | No |
| Fluor Equiv | 26W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 100W |
| Base | G24d (2-Pin) |
| Lamp Filament | LED |
| Shape | PL |
| Lamp Ballast Type | Type B |
| Brightness (Lumens) | 1750-1820 |
| Voltage | 120/277 |
| Wattage | 14 |
| Color Temperature (Kelvin) | 3000K/3500K/4000K/5000K/6500K |
| Material | Aluminum / Polycarbonate (PC) |
| Finish | White |
| THD | 20% |
| Operating Frequency | 50/60Hz |
| Operating Temp | -25C (-13F) to +50C (+122F) |
| Power Factor | >0.9 |
| Surge Protection | Built-in-surge protection - 0.5KV |
| Three-Way | No |
| MOD | 1.95" |
| MOL | 5.89" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0251 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 24 |
| Case Length | 10.04" |
| Case Width | 8.27" |
| Case Height | 15.16" |
| Case Weight | 12.1 |
| Case Cubic Ft. | 0.7284 |
| Catalog Description | 14 Watt LED PL - CCT Selectable - Lumens Selectable - Type B - Ballast Bypass - White Finish - 120/277 Volt |
| Description | 14W/PL/LED/HL/5CCT/G24 |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Ballasting Requirements | Ballast Bypass |
| Ballasting Requirements | Direct wire 120-277V line voltage |
| Ballasting Requirements | No ballast or external driver required |
| Enclosure Rating | Both |
| Image File Name | S21413.jpg |
| Installation Notes | Suggested wattage equivalency = 26W CFL |
| Minimum Compartment Size | Length: 6 in. Width: 6 in. Height: 8.5 in. |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 2.56 |
| Each Width In. | 2.36 |
| Each Height In. | 7.17 |
| Each Weight Lb. | 0.5 |
| Company | SATCO |
| Status | Active |
| Product Name | 14W LED PL CCT/Lumens Selectable Type B Ballast Bypass |
