SATCO NUVO's LED Hi-Pro Lamps offer a 320 degree rotating EX39 base making the installation of these lamps easier than ever. The two different on-unit CCT and Wattage Selectable switches give the user the power to customize the lighting for each unique environment. The notable design of the expandable light panels, when used in its fully open operating position, provides a 180 degree beam angle that enables the user to focus the light distribution exactly where it is needed the most. The outstanding heat dissipation, the ballast bypass feature, and the integrated 4kV surge protection make these the perfect HID replacement for shoebox fixtures and commercial area lighting. An optional 10kV hardwire surge protector is available to provide an additional level of protection when needed.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S28932R1 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S28932R1_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S28932R1_Dimensional_Diagram.pdf |
| Collection | Hi-Pro |
| Lighting Type | Lamps |
| Fixture Type | Expandable Hi-Pro |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | Cambodia |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | DLC, cULus |
| Location Rating | Damp |
| Indoor Outdoor | Outdoor |
| Amps | 0.500-0.217/0.583-0.253/0.667-0.289A |
| ANSI Base | EX39 |
| Ballast Bypass Direct | Ballast Bypass |
| Beam Spread | 180° |
| Burning Position | Universal |
| CCT Selectable | Yes |
| Color of Light | Soft White to Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| Dimming Technology | Through Wattage Selection Switch On Lamp |
| HID Equiv | 200W/250W/320W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 400W |
| Base | Mogul Extended |
| Lamp Filament | LED |
| Shape | Corncob |
| Lamp Ballast Type | Type B |
| Brightness (Lumens) | 9000/10150/11200 |
| Voltage | 120-277 |
| Wattage | 60/70/80 |
| Color Temperature (Kelvin) | 3000K/4000K/5000K |
| Material | Aluminum |
| Finish | White |
| THD | <20% |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 50/60Hz |
| Operating Temp | -30C (-22F) to +45C (+113F) |
| Power Factor | >0.9 |
| Surge Protection | Built-In Surge Protection - 4KV |
| Three-Way | Yes |
| MOD | 8.9" |
| MOL | 8.86" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.2201 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 4 |
| Case Length | 10.91" |
| Case Width | 12.01" |
| Case Height | 13.58" |
| Case Weight | 14.29 |
| Case Cubic Ft. | 1.0297 |
| Catalog Description | LED Shoe Box Lamp - 60/70/80 Wattage Selectable - 3K/4K/5K CCT Selectable - 120-277 Volt - White Finish |
| Description | 80W/LED/HID/SB/3CCT/EX39 |
| DLC Approved | Yes |
| UNSPSC | 39101628 |
| Ballasting Requirements | Ballast Bypass |
| Ballasting Requirements | Direct wire 120-277V line voltage |
| Ballasting Requirements | No ballast or external driver required |
| CO Terse | Lawful for Sale |
| Dimmable Function | Only dimmable through wattage selection switch on lamp |
| DLC Classification | Standard |
| DLC ID | S-ARHCWO |
| DLC Primary Use | Replacement Lamps for Outdoor Pole/Arm-Mounted Area and Roadway Luminaires (Type B) |
| Image File Name | S28932R1.jpg |
| Installation Notes | Not for use in vapor tight fixtures. |
| Minimum Compartment Size | Length: 11 in. Width: 11 in. Height: 9.2 in. |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 10.31 |
| Each Width In. | 5.71 |
| Each Height In. | 6.46 |
| Each Weight Lb. | 3.57 |
| Replaces | S28931 |
| Replaces | S28932 |
| Company | SATCO |
| Status | Active |
| Product Name | LED Shoe Box Lamp 60/70/80W Selectable 3K/4K/5K CCT |
