SATCO NUVO's LED Wrap fixtures offer superior lighting performance with a 90 CRI for enhanced color accuracy. Equipped with 5 CCT selectable technology, they provide customizable color temperatures and optimal illumination without glare, thanks to their closed-structure lens design. All models are NEC rated for closet use, adding to their versatility. The collection includes a standard version, a pull chain model for easy control, and a model with an integrated PIR sensor for energy-efficient motion detection. Ideal for areas requiring consistent lighting, such as closets, storage rooms, hallways, and utility spaces, these fixtures deliver reliable, energy saving illumination in residential, hospitality and light commercial settings.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=65-1213 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/65-1213_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/65-1213_Dimensional_Diagram.pdf |
| Lighting Type | Fixtures |
| Fixture Type | Ceiling Wrap |
| Fixture Shape | Linear |
| Tariff Code | 9405.11.6010 |
| Warranty | 5 Years |
| Country of Origin | Thailand |
| CA Web Text | Lawful for Sale |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 110° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | No |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 175W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 3200-3400 |
| Voltage | 120 |
| Wattage | 39 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Steel |
| Style | Utility |
| Finish | White |
| THD | <20% |
| Lens Finish | White |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.9 |
| Surge Protection | Built-In Surge Protection - 2.5KV |
| Mounting Type | Ceiling/Wall |
| Dimensions | L: 47.68" x W: 5.50" x H: 2.56" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.4452 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 4 |
| Case Length | 49.41" |
| Case Width | 11.81" |
| Case Height | 6.3" |
| Case Weight | 20.67 |
| Case Cubic Ft. | 2.1275 |
| Catalog Description | LED 4 Foot Wrap with Pull Chain - 39 Watts - 27K/30K/35K/40K/50K CCT Selectable - White Finish - 120 Volt |
| Description | 4FT 39W LED WRAP W/PULL CHAIN |
| Finish Family | White |
| UNSPSC | 39112507 |
| Image File Name | 65-1213.jpg |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 5.71 |
| Each Width In. | 2.76 |
| Each Height In. | 48.82 |
| Each Weight Lb. | 4.65 |
| Replaces | 65-1092 |
| Voltage Text | AC Only |
| Closet Rated | Yes |
| NEC Compliance | Clothes Closet Certified - Reg: 410.16 (A)(3) and 410.16 (C)(5) |
| Company | NUVO |
| Status | Active |
| Product Name | LED 4ft Wrap with Pull Chain 39W 27K/30K/35K/40K/50K CCT |
