SATCO NUVO's 65-1160 IP69K Rated LED UFO High Bay operates on 120-277V and is engineered for demanding industrial and hygienic environments requiring high-pressure, high-temperature wash-downs. NSF approved for sanitation-sensitive applications such as food processing and agriculture, this fixture features selectable wattage (200W/150W/100W) and CCT options (4000K/5000K) for on-site lighting customization. Built for harsh conditions, it includes IK10 impact resistance, 6kV surge protection, and an integrated respirator. The fixture is 0-10V dimmable and sensor ready with a 3.5mm auxiliary port, and a 6-foot Class 1 whip with waterproof connector and gasketed controls helps maintain its IP69K protective integrity.
| Tariff Code | 9405.11.6020 |
|---|---|
| UNSPSC | 39111546 |
| Warranty | 5-Years |
| Country of Origin | Vietnam |
| Additional Info | Metal Halide Equivalence: 200W-450W |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | Lawful for sale |
| CA Regulations | T20 Exempt - Fixtures Not Regulated |
| Title 20 | Exempt |
| T24 Compliant | No |
| Diameter In. | 14.99 |
| Dimension String | H:6.07" DIA:14.99" |
| Finish | White |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| IP Rating | IP69K |
| Material | Die-Cast Aluminum |
| Operating Temp | -40C (-40F) to +50C (+122F) |
| Safety Listing | cULus |
| Location Rating | Wet |
| SDS class | LED_Fixture |
| Technology | LED |
| Volts | 120V-277V |
| Voltage Text | Range Voltage;AC Only |
| Watts | 200W/150W/100W |
| Width In. | 14.99 |
| Height In. | 6.07 |
| Weight Lb. | 10.58 |
| Wire Color | White |
| Each UPC | 045923410147 |
| Each Quantity | 1 |
| Each Length In. | 15.94 |
| Each Width In. | 15.94 |
| Each Height In. | 5.83 |
| Each Weight Lb. | 13.12 |
| Each Cubic Ft. | 0.8572 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923410144 |
| Case Quantity | 1 |
| Case Length In. | 15.94 |
| Case Width In. | 15.94 |
| Case Height In. | 5.83 |
| Case Weight Lb. | 13.12 |
| Case Cubic Ft. | 0.8572 |
| Accessories | 86-237;86-238;86-239 |
| Specifications | https://www.satco.com/catalog/product/specsheets/65-1160 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/65-1160_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/65-1160_Dimensional_Diagram.pdf |
| ANSI Base | Integrated |
| Beam Spread | 85 |
| CCT Selectable | Yes |
| Color Temp | Cool White/Natural Light |
| Connection | Hardwire |
| CRI | 80 |
| Dimmable | Yes-Dimmable |
| Dimmable Function | 0-10V Dimming |
| DLC Approved | Yes |
| DLC Classification | Premium |
| DLC ID | S-5HF992 |
| DLC Primary Use | High-Bay Luminaires for Commercial and Industrial Buildings |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | UFO Hi-Bay |
| Avg Rated Hours | 50000 |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | Frost |
| Lens Material | Polycarbonate (PC) |
| Lumens | 30000L/22500L/15000L |
| Mounting Procedure | Ceiling: Loop/Hook/NPT adapter |
| NSF Approved | Yes |
| Operating Frequency | 50/60Hz |
| Power Factor | >0.9 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Style | Utility |
| Surge Protection | Built-in surge protection - 6KV |
| Temperature (CCT) | 4000K/5000K |
| THD | <20% |
| Wattage Selectable | Yes |
| Cord Length | 72 |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
