Overview
A 35/30/20W LED backlit flat panel delivering about 3850/3360/2280 lumens at selectable 3500/4000/5000K. Wattage and/or color temperature are field-selectable, so one SKU covers several job requirements. Rated life is 50,000 hours.
Features
- 35/30/20W power draw
- 3850/3360/2280 lumens at selectable 3500/4000/5000K
- CRI 80+ for accurate color rendering
- 120-277V input
- Panel
- 50,000 hour rated life
Specifications at a Glance
| Product Details | |
|---|---|
| Keystone Part # | KT-BPLED35PS-14E-8CSA-VDIM/FC5 |
| UPC | 843654175782 |
| Wattage | 35/30/20W |
| Brightness (Lumens) | 3850/3360/2280 |
| Color Temperature (Kelvin) | 3500/4000/5000K |
| Color Rendering Index (CRI) | 80+ |
| Input Voltage | 120-277V |
| Nominal Size | 1x4 |
| Avg Rated Hours | 50000 |
| Finish | White |
| Mounting | Retrofit |
| Construction | Panel |
| Case Quantity | 2 |
Applications
- Offices and conference rooms
- Schools
- Healthcare facilities
- Drop-ceiling retrofits
Compatibility
Rated for 120-277V input. Mounting: Retrofit.
Frequently Asked Questions
Q: Why is there a minimum order quantity?
A: Larger items like this cost more to ship, so the minimum order is 3.
| bundle | 1 |
|---|---|
| Product Name | 1x4 LED Backlit Flat Panel, 35/30/20W Selectable, 3500/4000/5000K, 120-277V |
| Company | KEYSTONE |
| Status | Active |
| spec sheet | https://keystonetech.widen.net/s/gbwspkj6tz/kt-bpledxxps-xxe-8csa-vdim_fc5 |
| Wattage | 35/30/20W |
| Brightness (Lumens) | 3850/3360/2280 |
| Color Temperature (Kelvin) | 3500/4000/5000K |
| Color Rendering Index (CRI) | 80+ |
| Input Voltage | 120-277V |
| Nominal Size | 1x4 |
| Avg Rated Hours | 50000 |
| Finish | White |
| Mounting | Retrofit |
| Construction | Panel |
| Case Quantity | 2 |
