New to SATCO NUVO, the TH5001 LED CCT Selectable track head fixture is finished in matte white, operates at 10 watts, and features a focused 36-degree beam angle-ideal for compact spotlighting applications. Now compatible with both Single Circuit and 2 Circuit J-Style track systems, this fixture offers expanded versatility. J-Style track is widely used in residential and commercial settings for its simple, streamlined connector design. With five color temperature options selectable at installation and a high 90 CRI for true-to-life color rendering, the TH5001 delivers efficient, modern lighting with precise control.
| Tariff Code | 9405.11.6020 |
|---|---|
| UNSPSC | 39111508 |
| Warranty | 3-Years |
| Country of Origin | Vietnam |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | Lawful for sale |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Dimension String | L:5.00" W:2.00" H:5.38" E:7.75" |
| Finish | Matte White |
| Indoor Outdoor | Indoor |
| Material | Aluminum / Steel |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Safety Listing | cETLus - Listed |
| Location Rating | Dry |
| Technology | LED |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 10W |
| Length In. | 5 |
| Width In. | 2 |
| Height In. | 5.38 |
| Extends In. | 7.75 |
| Weight Lb. | 0.7 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923408076 |
| Each Quantity | 1 |
| Each Length In. | 2.6 |
| Each Width In. | 2.2 |
| Each Height In. | 7.99 |
| Each Weight Lb. | 0.76 |
| Each Cubic Ft. | 0.0264 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923408073 |
| Case Quantity | 12 |
| Case Length In. | 9.61 |
| Case Width In. | 8.43 |
| Case Height In. | 8.98 |
| Case Weight Lb. | 9.07 |
| Case Cubic Ft. | 0.421 |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;MRF2S-6ELV;DVRF-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;DSE06-10Z;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL |
| Dimmers | -153P;LECL-153P;TTCL-100H;DVCL-253P;AYCL-253P;NTCL-250;TGCL-153PH;PD-6WCL;PD-10NXD;DVRF-6L;RRD-10D;RRD-6ND;RRD-H6BRL;HQRD-6ND;HQRD-10D;HQRD-10NBD;HQRD-HN6BRL;HQRD-6CL;RRD-6CL;RNL06-10Z;TAL06P-C2;DDMX1;86/103;S11268;6672;6674;IPL06;TSL06;DSM10;TSM10;6 |
| Dimmers | 6DF-10W;DSL06;DDL06;MAELV-600;SLV-600P;DW6HD;DH6HD;DG6HD;DZ6HD;DL6HD;DUL06P-C2;VSUL06D;RHCL450PTC;RH703PTUTC;WWRL50WH;REL06-WW;WSX-PDT-WH;RF9640-ND;SAL06P;ADTP703TU;DAL06P-C2;SUF7;NXFRD-UNV;S11270;80/2699;80/2700;80/2701;80/2702;80/2703;80/2704;PD-3P |
| Dimmers | CL;MRF2-3LD;MRF2-3PD;RRD-3LD;RRD-3PD;HQR-3LD;HQR-3PD;PHPM-WBX-120;ODMR0205;MR42400PLS |
| Specifications | https://www.satco.com/catalog/product/specsheets/TH5001 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/TH5001_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/TH5001_Dimensional_Diagram.pdf |
| ANSI Base | Integrated |
| Beam Spread | 36 |
| Bulb Volts | 120V |
| Bulb Watts | 10 |
| CCT Selectable | Yes |
| Color Temp | Warm White to Natural Light |
| CRI | 90+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Forward Phase; 120V only |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | Track Head |
| Has Emergency Battery | No |
| Avg Rated Hours | 30000 |
| Incandescent Equiv | 50W |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | Clear |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Lumens | 700L |
| Mounting Procedure | Track |
| Operating Frequency | 60Hz |
| Power Factor | >0.9 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Style | Contemporary |
| Surge Protection | Built-in surge protection - 2KV |
| Temperature (CCT) | 2700K/3000K/3500K/4000K/5000K |
| Track Head Style | Cylinder |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
