Crafted with simplicity and functionality at its core, SATCO NUVO's Blink Ultra Slim LED lighting is suited to countless application opportunities. SATCO NUVO'S S9886 9 inch round fixture in a white finish, is a perfect solution for installations where clearance and space are a premium. The ultra thin profile, at less than 1 inch, makes this fixture a convenient option for areas with very shallow ceilings. New construction, remodels, or retrofit installations...Blink's ultra-slim design is the ideal answer for difficult to illuminate spaces.
| Tariff Code | 9405.11.8020 |
|---|---|
| UNSPSC | 39111521 |
| Warranty | 3-Years |
| Country of Origin | China |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | Lawful for sale |
| CA Regulations | T20 Exempt - Fixtures Not Regulated |
| Title 20 | Exempt |
| T24 Compliant | No |
| Diameter In. | 9 |
| Dimension String | H:0.63" DIA:9.00" |
| ENERGY STAR | No |
| Finish | White |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| Material | Die-Cast Aluminum |
| Operating Temp | -17C (+1.4F) to +45C (+113F) |
| Safety Listing | cETLus - Listed |
| Location Rating | Damp |
| SDS class | LED_Lamp |
| Technology | LED |
| Volts | 120V/277V |
| Voltage Text | Dual Voltage |
| Watts | 16W |
| Width In. | 9 |
| Height In. | 0.63 |
| Weight Lb. | 1.08 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923098864 |
| Each Quantity | 1 |
| Each Length In. | 9.76 |
| Each Width In. | 12.01 |
| Each Height In. | 2.36 |
| Each Weight Lb. | 1.14 |
| Each Cubic Ft. | 0.1601 |
| Pack Type | Color Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923098861 |
| Case Quantity | 12 |
| Case Length In. | 20.16 |
| Case Width In. | 12.8 |
| Case Height In. | 14.96 |
| Case Weight Lb. | 16.67 |
| Case Cubic Ft. | 2.234 |
| Substitute | 62-1720 |
| Dimmers | CTRP-253P;DSM10-1LZ;DVCL-153P;DVRP-253P;NTCL-250;NTRP-250;PD-6WCL;TAL06P-C2 |
| Accessories | 62-1302 |
| Specifications | https://www.satco.com/catalog/product/specsheets/S9886 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/S9886_Installation_Instructions.pdf |
| ANSI Base | Integrated |
| Beam Spread | 108 |
| CCT Selectable | No |
| Color Temp | Warm White |
| Connection | Direct Wired |
| CRI | 90+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Forward Phase or Reverse Phase; 120V only |
| DLC Approved | No |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | BLINK Slim |
| Has Emergency Battery | No |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 100W |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | Frost |
| Lens Material | Glass |
| Lumens | 1300L |
| Mounting Procedure | Ceiling/Wall |
| Operating Frequency | 50/60Hz |
| Power Factor | 0.98 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Style | Utility |
| Temperature (CCT) | 3000K |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
