SATCO NUVO's innovative CFL replacement lamps provide an efficient solution for upgrading older 18W, 26W, or 32W CFL fixtures to the energy-saving advantages of LED technology. These lamps are compatible with three distinct ballast options, providing flexibility for your existing setup. Type A/B and Type A lamps are ideal for replacing older CFLs without requiring rewiring, while Type B lamps are perfect for installations without a ballast. With two base options available-G24q (4-pin) and G24d (2-pin)-and color temperatures from 2700K to 4000K, users can tailor their lighting to suit diverse environments. Delivering a broad range of lumen outputs, our lamps offer exceptional versatility and long-lasting performance, making them an excellent choice for both residential and commercial spaces.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S29856 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S29856_Instructions.pdf |
| Lighting Type | Lamps |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | Thailand |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cRUus, cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| Amps | 0.079-0.034A |
| ANSI Base | G24q |
| Ballast Bypass Direct | Direct |
| Beam Spread | 360° |
| Burning Position | Universal |
| CCT Selectable | Yes |
| Color of Light | Warm to Cool White |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| Dimming Technology | With Compatible Dimming Ballasts |
| Fluor Equiv | 18W/26W/32W |
| Avg Rated Hours | 50000 |
| Base | G24q (4-Pin) |
| Lamp Filament | LED |
| Shape | PL |
| Lamp Ballast Type | Type A |
| Brightness (Lumens) | 1100/1150/1200 |
| Wattage | 9.5 |
| Color Temperature (Kelvin) | 3000K/3500K/4000K |
| Material | Aluminum / Plastic |
| Finish | Frost |
| THD | <20% |
| Operating Frequency | 50/60Hz |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Power Factor | 0.9 |
| Three-Way | No |
| MOD | 1.4" |
| MOL | 6.9" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0086 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 24 |
| Case Length | 9.33" |
| Case Width | 6.42" |
| Case Height | 7.95" |
| Case Weight | 6.3 |
| Case Cubic Ft. | 0.28 |
| Catalog Description | 9.5 Watt LED PL - 30K/35K/40K CCT Selectable - G24q Base - Type A |
| Description | 9.5W/LED/CFL/3CCT/DR/4P |
| UNSPSC | 39101628 |
| Ballasting Requirements | Ballast required, check compatibility |
| Dimmable Function | Only Dimmable with Compatible Dimming Ballasts |
| Enclosure Rating | Enclosed Rated Lamp |
| Image File Name | S29856.jpg |
| NSF Approved | Yes |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 1.46 |
| Each Width In. | 1.46 |
| Each Height In. | 7.01 |
| Each Weight Lb. | 0.25 |
| Company | SATCO |
| Status | Active |
| Product Name | 9.5W LED PL 30K/35K/40K CCT Selectable G24q Base Type A |
