Elevate your lighting experience with SATCO NUVO's R14 reflector LED light bulbs. Engineered for top-tier energy efficiency, these bulbs deliver vibrant, true-to-life white light with a high color rendering index (CRI) of 90. Choose between the inviting warmth of 3000K soft white or the crisp clarity of 5000K natural light. Available with E17 intermediate and E26 medium bases, they seamlessly integrate into a variety of fixtures. With a wide 110 degree beam angle and smooth dimming capability down to 10 percent, these versatile bulbs offer customizable lighting solutions for any environment. Whether it's illuminating living spaces, dining areas, or commercial establishments like offices, museums, or retail stores, these bulbs ensure the perfect ambiance for every occasion.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S12261 |
| Lighting Type | Lamps |
| Tariff Code | 8539.52.0030 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| CBCP | 90 |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| Amps | 0.029A |
| ANSI Base | E17 |
| Beam Spread | 110° |
| Candle Power | 90 |
| CCT Selectable | No |
| Color of Light | Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Dimming Technology | 120V |
| Avg Rated Hours | 25000 |
| Incandescent Equiv | 40W |
| Base | Intermediate |
| Lamp Filament | LED |
| Shape | R14 |
| Brightness (Lumens) | 300 |
| Voltage | 120 |
| Wattage | 3.5 |
| Color Temperature (Kelvin) | 5000K |
| Material | Plastic |
| Finish | Frost |
| THD | 26% |
| Lens Finish | Frost |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 60Hz |
| Operating Temp | -25C (-13F) to +45C (+113F) |
| Power Factor | 0.9 |
| Surge Protection | Built-In Surge Protection - 2.5KV |
| Three-Way | No |
| MOD | 1.78" |
| MOL | 2.56" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0272 |
| Pack Type | Carded |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 12 |
| Case Length | 12.99" |
| Case Width | 9.65" |
| Case Height | 7.28" |
| Case Weight | 1.08 |
| Case Cubic Ft. | 0.5281 |
| Catalog Description | 3.5 Watt - R14 LED - Intermediate Base - 5000K CCT - Frost Finish - 120 Volt |
| Description | 3.5R14/LED/950/E17/120V |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Dimmable Function | 120V only |
| Enclosure Rating | Enclosed Rated Lamp |
| Image File Name | S12261.jpg |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 4.06 |
| Each Width In. | 1.78 |
| Each Height In. | 6.5 |
| Each Weight Lb. | 0.08 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | IPE04-1L |
| Dimmers | 66ELV |
| Dimmers | VPE06-1LZ |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | DVCL-253P |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | RRD-10D |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | 66DF-10W |
| Dimmers | DSL06 |
| Dimmers | DDL06 |
| Dimmers | MAELV-600 |
| Dimmers | SLV-600P |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DZ6HD |
| Dimmers | DL6HD |
| Dimmers | DUL06P-C2 |
| Dimmers | VSUL06D |
| Dimmers | RHCL450PTC |
| Dimmers | WSX-PDT-WH |
| Dimmers | RF9640-ND |
| Dimmers | SAL06P |
| Dimmers | ADTP703TU |
| Dimmers | DAL06P-C2 |
| Dimmers | SUF7 |
| Dimmers | NXFRD-UNV |
| Dimmers | S11270 |
| Dimmers | 80/2699 |
| Dimmers | 80/2700 |
| Dimmers | 80/2701 |
| Dimmers | 80/2702 |
| Dimmers | 80/2703 |
| Dimmers | 80/2704 |
| Dimmers | PD-3PCL |
| Dimmers | MRF2-3LD |
| Dimmers | MRF2-3PD |
| Dimmers | RRD-3LD |
| Dimmers | RRD-3PD |
| Dimmers | HQR-3LD |
| Dimmers | HQR-3PD |
| Dimmers | PHPM-WBX-120 |
| Dimmers | ODMR0205 |
| Dimmers | MR42400PLS |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL-153P;LECL-153P;TTCL-100H;DVC |
| Company | SATCO |
| Status | Active |
| Product Name | 3.5W R14 LED Intermediate Base 5000K Frost Finish 120V |
