Satco's 4 watt T5 LED Type B miniature bi-pin replaces traditional linear lamps with a no ballast, no external driver option for lasting retrofit conversion. With double ended wiring for convenience, the frosted bulb has a temperature of 4000 kelvins and a lumens count of 400. Providing 50,000 hours of cool white light, this bulb is PET coated for shatterproof protection.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S11905 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S11905_Instructions.pdf |
| Lighting Type | Lamps |
| Fixture Type | Linear |
| Tariff Code | 8539.52.0051 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus, ETLus |
| Location Rating | Damp |
| Amps | 0.033-0.014A |
| ANSI Base | G5 |
| Ballast Bypass Direct | Ballast Bypass |
| Beam Spread | 240° |
| Burning Position | Universal |
| CCT Selectable | No |
| Color of Light | Cool White |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | No |
| Fluor Equiv | 8W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 25W |
| Base | Miniature Bi Pin |
| Lamp Filament | LED |
| Shape | T5 |
| Lamp Ballast Type | Type B |
| Lamp End Type | Double |
| Brightness (Lumens) | 400 |
| Voltage | 120-277 |
| Wattage | 4 |
| Color Temperature (Kelvin) | 4000K |
| Material | Glass |
| Finish | Frost |
| THD | 20% |
| Lensed | Yes |
| Lens Finish | Frost |
| Operating Frequency | 50/60Hz |
| Operating Temp | -25C (-13F) to +45C (+113F) |
| Power Factor | 0.9 |
| Shatter Proof Type | PET Coated |
| Surge Protection | Built-in-surge protection - 0.5KV |
| Three-Way | No |
| MOD | 0.83" |
| MOL | 11.91" |
| Nominal Length | 12" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0056 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 10 |
| Inner Length | 13.2" |
| Inner Width | 5.3" |
| Inner Height | 2.8" |
| Inner Weight | 0.8 |
| Inner Cubic Ft. | 0.1134 |
| Case UPC | 10045900000000 |
| Case Quantity | 100 |
| Case Length | 14.76" |
| Case Width | 11.02" |
| Case Height | 12.6" |
| Case Weight | 8.07 |
| Case Cubic Ft. | 1.186 |
| Catalog Description | 4 Watt T5 LED - Miniature bi-pin base - 4000K - 50000 Average rated hours - 400 Lumens - 120-277 Volt - Type B - Ballast Bypass - Double Ended Wiring |
| Description | 4W/LED/T5/840/BP |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Ballasting Requirements | No ballast or external driver required |
| CO Terse | Lawful for Sale |
| HI Terse | Lawful for Sale |
| NV Terse | Lawful for sale |
| VT Terse | Lawful for sale |
| WA Terse | Lawful for sale |
| Enclosure Rating | Enclosed Rated Lamp |
| Image File Name | S11905.jpg |
| Installation Notes | Not for use in vapor tight fixtures. Direct wire 120-277V line voltage |
| Installation Notes | Double ended wiring |
| NSF Approved | Yes |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 12 |
| Each Width In. | 0.9 |
| Each Height In. | 0.9 |
| Each Weight Lb. | 0.15 |
| Company | SATCO |
| Status | Active |
| Product Name | 4W T5 LED Mini Bi-Pin Base 4000K 50000 Hrs 400 Lumens |
