Transform your surroundings with SATCO NUVO's selection of GY6.35, G8, and G9 Halogen replacement lamps, engineered for optimal energy efficiency and affordability. Offering a range of shapes, bases, CCT's, and finishes, these lamps utilize cutting-edge LED technology for substantial long-term savings. Emitting a 300-degree omni-directional light, these lamps are ideal for accentuating various settings including chandeliers, display lighting, landscapes, and displays. Explore our diverse selection to find the perfect lighting solution to deliver brilliantly focused light, tailored to meet your requirements.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S11239 |
| Lighting Type | Lamps |
| Fixture Type | LED |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| IP Rating | IP20 |
| Amps | 0.042A |
| ANSI Base | G9 |
| Beam Spread | 300° |
| Burning Position | Universal |
| CCT Selectable | No |
| Color of Light | Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| HID Equiv | 40W |
| Avg Rated Hours | 25000 |
| Base | G9 Double Loop |
| Lamp Filament | LED |
| Shape | T4 |
| Brightness (Lumens) | 550 |
| Voltage | 120 |
| Wattage | 5 |
| Color Temperature (Kelvin) | 5000K |
| Material | Ceramic / Polycarbonate (PC) |
| Finish | Clear |
| THD | 70% |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.9 |
| Three-Way | No |
| MOD | 0.75" |
| MOL | 2.13" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0042 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 20 |
| Inner Length | 8.07" |
| Inner Width | 3.35" |
| Inner Height | 6.42" |
| Inner Weight | 1.22 |
| Inner Cubic Ft. | 0.1004 |
| Case UPC | 10045900000000 |
| Case Quantity | 200 |
| Case Length | 17.44" |
| Case Width | 8.66" |
| Case Height | 13.62" |
| Case Weight | 13.23 |
| Case Cubic Ft. | 1.1904 |
| Catalog Description | 5 Watt G9 LED - Clear - 5000K - T4 Shape - 120 Volt |
| Description | 5W/LED/G9/850/CL/120V/DIM |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Enclosure Rating | Enclosed Rated Lamp |
| Image File Name | S11239.jpg |
| Installation Notes | Not for use in vapor tight fixtures. For proper ventilation, original protective glass shield for halogen lamps should be removed during installation. |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 1.57 |
| Each Width In. | 1.57 |
| Each Height In. | 2.95 |
| Each Weight Lb. | 0.06 |
| Replaces | S29549 |
| Replaces | S9227 |
| Replaces | S9549 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | IPE04-1L |
| Dimmers | 66ELV |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | RRD-10D |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | DSL06 |
| Dimmers | MAELV-600 |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DL6HD |
| Dimmers | DZ6HD |
| Dimmers | RHCL450PTC |
| Dimmers | ADTP703TU |
| Dimmers | DAL06P-C2 |
| Dimmers | SUF7 |
| Dimmers | PHPM-WBX-120 |
| Dimmers | DVCL-253P |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL-153P;LECL-153P;TTCL-100H;AYCL-253P;NTC |
| Company | SATCO |
| Status | Active |
| Product Name | 5W G9 LED 5000K T4 Shape 120V Clear |
