The SATCO NUVO JH5065 LED Track Head delivers adaptable lighting with a broader 48-degree beam angle. This black, round J-style fixture features 5 CCT selectability, Dim to Warm performance, precise aiming, and a prismatic lens for enhanced beam quality.
| Tariff Code | 9405.11.6020 |
|---|---|
| UNSPSC | 39111508 |
| Warranty | 3-Years |
| Country of Origin | Malaysia |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| ADA Compliant | No |
| CA Web Text | Lawful for sale |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Diameter In. | 2.28 |
| Dimension String | L:2.87" H:2.27" DIA:2.27" E:5.00" |
| ENERGY STAR | No |
| Finish | Black |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| Material | Aluminum |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Safety Listing | cETLus |
| Location Rating | Dry |
| SDS class | LED_Fixture |
| Technology | LED |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 8W |
| Length In. | 2.87 |
| Height In. | 2.27 |
| Extends In. | 5 |
| Weight Lb. | 0.51 |
| Each UPC | 045923412790 |
| Each Quantity | 1 |
| Each Length In. | 2.95 |
| Each Width In. | 2.68 |
| Each Height In. | 5.31 |
| Each Weight Lb. | 0.56 |
| Each Cubic Ft. | 0.0243 |
| Pack Type | Kraft Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923412797 |
| Case Quantity | 24 |
| Case Length In. | 16.85 |
| Case Width In. | 6.5 |
| Case Height In. | 11.42 |
| Case Weight Lb. | 13.44 |
| Case Cubic Ft. | 0.7238 |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;MRF2S-6ELV;DVRF-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;DSE06-10Z;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL |
| Dimmers | -153P;LECL-153P;TTCL-100H;DVCL-253P;AYCL-253P;NTCL-250;TGCL-153PH;PD-6WCL;PD-10NXD;DVRF-6L;RRD-10D;RRD-6ND;RRD-H6BRL;HQRD-6ND;HQRD-10D;HQRD-10NBD;HQRD-HN6BRL;HQRD-6CL;RRD-6CL;RNL06-10Z;TAL06P-C2;DDMX1;86/103;S11268;6672;6674;IPL06;DSL06;TSL06;DSM10;T |
| Dimmers | SM10;66DF-10W;DDL06;MAELV-600;SLV-600P;DW6HD;DH6HD;DG6HD;DZ6HD;DL6HD;DUL06P-C2;VSUL06D;RH703PTUTC;WWRL50WH;REL06-WW;WSX-PDT-WH;RF9640-ND;SAL06P;ADTP703TU;SUF7;NXFRD-UNV;S11270;80/2699;80/2700;80/2701;80/2702;80/2703;80/2704;PD-3PCL;MRF2-3LD;MRF2-3PD; |
| Dimmers | RRD-3LD;RRD-3PD;HQR-3LD;HQR-3PD;PHPM-WBX-120;ODMR0205;MR42400PLS |
| Specifications | https://www.satco.com/catalog/product/specsheets/JH5065 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/JH5065_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/JH5065_Dimensional_Diagram.pdf |
| ANSI Base | Integrated |
| Beam Spread | 48 |
| CCT Selectable | Yes |
| Closet Rated | No |
| Color Temp | Warm White to Natural Light; Warm Dimming |
| Connection | Connector or Adapter |
| CRI | 90+ |
| Dark Sky Rated | No |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Forward or Reverse Phase; 120V only |
| FCC Compliant | Yes |
| Finish Family | Black |
| Product Type | Track Head |
| Flicker Free | Yes |
| Has Emergency Battery | No |
| Avg Rated Hours | 50000 |
| OSHA Compliant | No |
| Incandescent Equiv | 40W |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | Clear |
| Lens Material | Polycarbonate (PC) |
| Lumens | 500L-600L |
| Mounting Length | 2.25 |
| Mounting Width | 2.25 |
| Mounting Height | 4.25 |
| NSF Approved | No |
| Operating Frequency | 60Hz |
| Power Factor | >0.92 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Sloped Ceiling Compatible | Yes |
| Style | Contemporary |
| Surge Protection | Built-in surge protection - 2.5KV |
| Temperature (CCT) | 2700K/3000K/3500K/4000K/5000K/3000K-2000K |
| THD | <100% |
| Track Head Style | J-Style |
| Up Down Installation | Universal |
| Wattage Selectable | No |
