SATCO NUVO's 65-813 Round High Bay Field Selectable fixture in a white finish, offers an energy efficient and low-maintenance alternative to traditional HID fixtures. This luminary is field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixture is constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location ratings, this high bay is resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) this fixture can be customized to accommodate a multitude of lighting needs.
| Tariff Code | 9405.11.6020 |
|---|---|
| UNSPSC | 26121536 |
| Warranty | 5-Years |
| Country of Origin | Vietnam |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | Lawful for sale |
| CA Regulations | T20 Exempt - Fixtures Not Regulated |
| Title 20 | Exempt |
| T24 Compliant | No |
| Diameter In. | 13.4 |
| Dimension String | H:7.30" DIA:13.40" |
| Finish | White |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| Includes | Locking Hanging Hook; 6 Foot Whip |
| IP Rating | IP65 |
| Material | Die-Cast Aluminum |
| Operating Temp | -40C (-40F) to +50C (+122F) |
| Safety Listing | cULus - Certified |
| Location Rating | Wet |
| SDS class | LED_Fixture |
| Technology | LED |
| Volts | 120V-347V |
| Voltage Text | Range Voltage;AC Only |
| Watts | 150W/175W/200W |
| Width In. | 13.4 |
| Height In. | 7.3 |
| Weight Lb. | 6.42 |
| Wire Length In. | 72 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923651960 |
| Each Quantity | 1 |
| Each Length In. | 14.17 |
| Each Width In. | 14.17 |
| Each Height In. | 4.92 |
| Each Weight Lb. | 7.99 |
| Each Cubic Ft. | 0.5717 |
| Pack Type | Brown Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923651967 |
| Case Quantity | 1 |
| Case Length In. | 14.17 |
| Case Width In. | 14.17 |
| Case Height In. | 4.92 |
| Case Weight Lb. | 7.99 |
| Case Cubic Ft. | 0.5717 |
| Dimmers | ADPD4FBL3P2W4;RH4FBL3PTCCCV6;CD4FBLW;SF10P;DS710-10Z;DVSCSTV;DVSTV;NFTV;IP710-LFZ;MS-Z101;MS-Z101-V;NTSTV-DV;RMJS-8T-DV-B + PJ2-3BRL-GWH-L01;DF10P;DVTV + PP347H 347V ONLY |
| Accessories | 65-170;65-200;65-759;65-779;65-799;65-800;65-810;65-815;86-217;86-218;86-219;86-220;65-764 |
| Specifications | https://www.satco.com/catalog/product/specsheets/65-813 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/65-813_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/65-813_Dimensional_Diagram.pdf |
| ANSI Base | Integrated |
| Beam Spread | 90 |
| CCT Selectable | Yes |
| Color Temp | Warm White to Natural Light |
| CRI | 80+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | 0-10V Dimming Only |
| DLC Approved | Yes |
| DLC Classification | Premium |
| DLC ID | S-PQ3SZK |
| DLC Primary Use | High-Bay Luminaires for Commercial and Industrial Buildings |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | UFO Hi-Bay |
| Has Emergency Battery | No |
| HID Equiv | 400W-450W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 1000W/1500W/2000W |
| Installation Notes | Mounting Height: Up to 20 feet |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | Clear |
| Lens Material | Polycarbonate (PC) |
| Lumens | 22200L-28800L |
| Mounting Procedure | Pendant Hanging Surface |
| NSF Approved | Yes |
| Operating Frequency | 50/60Hz |
| Power Factor | 0.9 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Style | Utility |
| Surge Protection | Built-in surge protection - 6KV |
| Temperature (CCT) | 3000K/4000K/5000K |
| THD | 15% |
| Wattage Selectable | Yes |
| Photocell | Optional Add-On |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
