SATCO NUVO's Round High Bay Field Selectable fixtures offer an energy efficient and low-maintenance alternative to traditional HID fixtures. These luminaires are field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixtures are constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location rating, these high bays are resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) fixtures can be customized to accommodate a multitude of lighting needs.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=65-771R3 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/65-771R3_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/65-771R3_Dimensional_Diagram.pdf |
| Lighting Type | Fixtures |
| Fixture Type | UFO Hi-Bay |
| Fixture Shape | Round |
| Tariff Code | 9405.11.6020 |
| Warranty | 5 Years |
| Country of Origin | Vietnam |
| CA Web Text | Lawful for Sale |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | DLC, cULus |
| Location Rating | Wet |
| Indoor Outdoor | Indoor |
| IP Rating | IP65 |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 90° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| Dimming Technology | 0-10V |
| HID Equiv | 400W-450W |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 1000W/1500W/2000W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 22200-28800 |
| Voltage | 120-347 |
| Wattage | 150/175/200 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 3000K/4000K/5000K |
| Material | Die-Cast Aluminum |
| Style | Utility |
| Finish | Black |
| THD | 15% |
| Lens Finish | Clear |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 50/60Hz |
| Operating Temp | -40C (-40F) to +50C (+122F) |
| Photocell | Optional Add-On |
| Power Factor | 0.9 |
| Surge Protection | Built-In Surge Protection - 6KV |
| Wire Cord Length | 72" |
| Mounting Type | Pendant Hanging Surface |
| Wattage Selectable | Yes |
| Diameter | 13.4" |
| Dimensions | H: 7.30" x DIA: 13.40" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.5717 |
| Pack Type | Brown Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 1 |
| Case Length | 14.17" |
| Case Width | 14.17" |
| Case Height | 4.92" |
| Case Weight | 7.99 |
| Case Cubic Ft. | 0.5717 |
| Catalog Description | Wattage 150W/175W/200W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish |
| Description | LED UFO HIGHBAY CCT & WATT ADJ |
| Wire Length | 72" |
| Finish Family | Black |
| DLC Approved | Yes |
| UNSPSC | 26121536 |
| Dimmable Function | 0-10V Dimming Only |
| DLC Classification | Premium |
| DLC ID | S-PQ3SZK |
| DLC Primary Use | High-Bay Luminaires for Commercial and Industrial Buildings |
| Image File Name | 65-771R3.jpg |
| Includes | Locking Hanging Hook |
| Includes | 6 Foot Whip |
| Installation Notes | Mounting Height: Up to 20 feet |
| NSF Approved | Yes |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 14.17 |
| Each Width In. | 14.17 |
| Each Height In. | 4.92 |
| Each Weight Lb. | 7.99 |
| Replaces | 65-771 |
| Replaces | 65-771R1 |
| Replaces | 65-771R2 |
| Dimmers | ADPD4FBL3P2W4 |
| Dimmers | RH4FBL3PTCCCV6 |
| Dimmers | CD4FBLW |
| Dimmers | SF10P |
| Dimmers | DS710-10Z |
| Dimmers | DVSCSTV |
| Dimmers | DVSTV |
| Dimmers | NFTV |
| Dimmers | IP710-LFZ |
| Dimmers | MS-Z101 |
| Dimmers | MS-Z101-V |
| Dimmers | NTSTV-DV |
| Dimmers | RMJS-8T-DV-B + PJ2-3BRL-GWH-L01 |
| Dimmers | DF10P |
| Dimmers | DVTV + PP347H 347V ONLY |
| Voltage Text | Range Voltage |
| Voltage Text | AC Only |
| Accessories | 65-169 |
| Accessories | 65-199 |
| Accessories | 65-766 |
| Accessories | 65-769 |
| Accessories | 65-779 |
| Accessories | 65-799 |
| Accessories | 65-800 |
| Accessories | 65-810 |
| Accessories | 65-815 |
| Accessories | 86-217 |
| Accessories | 86-218 |
| Accessories | 86-219 |
| Accessories | 86-220 |
| Company | NUVO |
| Status | Active |
| Product Name | 150W/175W/200W LED UFO High Bay 3K/4K/5K 120-347V |
