Slim, sleek, and designed to do more- SATCO NUVO's CounterQuick Slim undercabinet lighting brings both dramatic accent and practical task lighting to spaces where traditional fixtures simply can't. Its ultra-low profile and contemporary black or white finish complement any décor, while selectable color temperatures (3000K/4000K/5000K) let you tailor the ambiance from warm and inviting to bright and energizing. Designed for ultimate versatility, these fixtures come in multiple lengths, connect seamlessly for extended runs, and can be expanded with optional accessories. Whether brightening kitchen countertops, adding depth to office shelving, or creating atmosphere in hospitality settings, CounterQuick Slim delivers style and performance in one smart, streamlined solution. CounterQuick Slim…light where you need it, style where you want it!
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=63-453 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/63-453_Instructions.pdf |
| Collection | CounterQuick |
| Lighting Type | Fixtures |
| Fixture Type | Under Cabinet |
| Tariff Code | 9405.42.6000 |
| Warranty | 5 Years |
| Country of Origin | Thailand |
| CA Web Text | Lawful for Sale |
| Flicker Free | No |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 110° |
| CCT Selectable | Yes |
| Color of Light | Soft White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 40W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 500 |
| Voltage | 120 |
| Wattage | 8 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 3000K/4000K/5000K |
| Material | Polycarbonate (PC) |
| Style | Contemporary |
| Finish | Black |
| THD | <30% |
| Lens Finish | Frost |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Power Factor | >0.9 |
| Surge Protection | Built-in-surge protection - 0.5KV |
| Connection | Hardwire |
| Mounting Type | Under Cabinet Clip |
| Dimensions | L: 21" x W: 0.70" x H: 0.78" x D: 0.78" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.019 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 12 |
| Inner Length | 22.86" |
| Inner Width | 4.17" |
| Inner Height | 3.54" |
| Inner Weight | 4.62 |
| Inner Cubic Ft. | 0.1953 |
| Case UPC | 10045900000000 |
| Case Quantity | 48 |
| Case Length | 22.3" |
| Case Width | 12.3" |
| Case Height | 6.9" |
| Case Weight | 21.14 |
| Case Cubic Ft. | 1.0953 |
| Catalog Description | 8 Watt 21-Inch LED Under Cabinet - 30K/40K/50K CCT Selectable - Black Finish - 120 Volt |
| Description | 8W 21" CCT SEL LED UNDERCABINE |
| Finish Family | Black |
| UNSPSC | 26121536 |
| Image File Name | 63-453.jpg |
| Installation Notes | Minimum Installation Area: 24" x 4" x 4" |
| Technology | LED |
| Each Length In. | 21.1 |
| Each Width In. | 1.97 |
| Each Height In. | 0.79 |
| Each Weight Lb. | 0.37 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | MRF2S-6ELV |
| Dimmers | DVRF-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | IPE04-1L |
| Dimmers | 66ELV |
| Dimmers | DSE06-10Z |
| Dimmers | VPE06-1LZ |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | DVCL-253P |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | DVRF-6L |
| Dimmers | RRD-10D |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | 86/103 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | 66DF-10W |
| Dimmers | DSL06 |
| Dimmers | DDL06 |
| Dimmers | MAELV-600 |
| Dimmers | SLV-600P |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DZ6HD |
| Dimmers | DL6HD |
| Dimmers | DUL06P-C2 |
| Dimmers | VSUL06D |
| Dimmers | RHCL450PTC |
| Dimmers | RH703PTUTC |
| Dimmers | WWRL50WH |
| Dimmers | REL06-WW |
| Dimmers | WSX-PDT-WH |
| Dimmers | RF9640-ND |
| Dimmers | SAL06P |
| Dimmers | ADTP703TU |
| Dimmers | DAL06P-C2 |
| Dimmers | SUF7 |
| Dimmers | NXFRD-UNV |
| Dimmers | S11270 |
| Dimmers | 80/2699 |
| Dimmers | 80/2700 |
| Dimmers | 80/2701 |
| Dimmers | 80/2702 |
| Dimmers | 80/2703 |
| Dimmers | 80/2704 |
| Dimmers | PD-3PCL |
| Dimmers | MRF2-3LD |
| Dimmers | MRF2-3PD |
| Dimmers | RRD-3LD |
| Dimmers | RRD-3PD |
| Dimmers | HQR-3LD |
| Dimmers | HQR-3PD |
| Dimmers | PHPM-WBX-120 |
| Dimmers | ODMR0205 |
| Dimmers | MR42400PLS |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;MRF2S-6ELV;DVRF-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;IPE04-1L;66ELV;DSE06-10Z;VPE06-1LZ;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTC |
| Voltage Text | AC Only |
| Accessories | 63-461 |
| Accessories | 63-462 |
| Accessories | 63-463 |
| Accessories | 63-464 |
| Accessories | 63-465 |
| Accessories | 63-466 |
| Accessories | 63-467 |
| Accessories | 63-468 |
| Accessories | 63-469 |
| Accessories | 63-470 |
| Accessories | 63-471 |
| Accessories | 63-472 |
| Accessories | 63-431 |
| Accessories | 63-432 |
| Closet Rated | No |
| Connectable Units | 37 |
| Company | NUVO |
| Status | Active |
| Product Name | 8W 21-Inch LED Under Cabinet 30K/40K/50K CCT Selectable Black |
