SATCO NUVO's 18-inch LED Wrap Fixture delivers both illumination and power exactly where you need it. Perfect for workshops, apartment complexes, and multi-family dwellings, this fixture is ideal for areas where space is limited, and convenient power access is essential. The 15-amp, dual tamper-resistant GFCI outlets effortlessly meet all your power needs while providing safety and circuit overload protection. The front-facing outlet design enhances accessibility, while the easy-to-read LED status light keeps you informed, ensuring a safe and worry-free experience.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=62-700 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/62-700_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/62-700_Dimensional_Diagram_1.pdf |
| Lighting Type | Fixtures |
| Fixture Type | Ceiling Wrap |
| Tariff Code | 9405.11.6010 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| ADA Compliant | Yes |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 110° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | No |
| Avg Rated Hours | 50000 |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 1298-1391 |
| Voltage | 120 |
| Wattage | 14 |
| Bulb Watt | 14 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Steel |
| Finish | White |
| THD | <30% |
| Lens Finish | White |
| Lens Material | Polycarbonate (PC) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.9 |
| Surge Protection | Built-In Surge Protection - 2KV |
| Wire Gauge | 14 |
| Mounting Type | Ceiling/Wall |
| Extension | 2.51" |
| Dimensions | L: 18" x W: 4.40" x E: 2.50" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.136 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 6 |
| Case Length | 18.9" |
| Case Width | 8.86" |
| Case Height | 10.04" |
| Case Weight | 15.23 |
| Case Cubic Ft. | 0.9729 |
| Catalog Description | 14 Watt 18 Inch LED Ceiling Wrap - Dual GFCI - 27K/30K/35K/40K/50K CCT Selectable |
| Description | LED 18" WRAP WITH DUAL GFCIS |
| Finish Family | White |
| UNSPSC | 39112507 |
| Image File Name | 62-700.jpg |
| Installation Notes | Standard 3-inch and 4-inch Keyhole Slots |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 18.31 |
| Each Width In. | 2.76 |
| Each Height In. | 4.65 |
| Each Weight Lb. | 2.54 |
| Bulb Volts | 120V |
| Voltage Text | AC Only |
| Company | NUVO |
| Status | Active |
| Product Name | 14W 18" LED Ceiling Wrap Dual GFCI CCT Selectable |
