Introducing SATCO NUVO's 62-1800 Contractor Packs CCT Selectable Disk Light, a 7-inch, 15-watt solution designed to fit perfectly in various applications. Our ColorQuick technology offers five different color temperatures for creating the perfect ambiance. Rated for 50,000 hours, and featuring a high CRI of 93, 2.5kV surge protection, and wet location rating, this disk light is built to the highest quality, perfect for any interior environment.
| Tariff Code | 9405.11.8020 |
|---|---|
| UNSPSC | 26121536 |
| Warranty | 5-Years |
| Country of Origin | Malaysia |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | California T24 Listed |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Diameter In. | 7.42 |
| Dimension String | H:1.42" DIA:7.42" |
| ENERGY STAR | No |
| Finish | White |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| Material | Steel |
| Operating Temp | -25C (-13F) to +40C (+104F) |
| Safety Listing | cETLus - Listed |
| Location Rating | Wet |
| SDS class | LED_Fixture |
| Technology | LED |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 15W |
| Width In. | 7.42 |
| Height In. | 1.42 |
| Weight Lb. | 0.58 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923625855 |
| Each Quantity | 1 |
| Each Length In. | 7.67 |
| Each Width In. | 7.67 |
| Each Height In. | 10.03 |
| Each Weight Lb. | 4.497 |
| Each Cubic Ft. | 0.3415 |
| Pack Type | Contractor Box |
| Quantity In Pack | 6 |
| Case UPC | 10045923625852 |
| Case Quantity | 4 |
| Case Length In. | 15.94 |
| Case Width In. | 15.94 |
| Case Height In. | 10.629 |
| Case Weight Lb. | 19.581 |
| Case Cubic Ft. | 1.5629 |
| Dimmers | 6672;6674;66DF-10W;66ELV;66EV-10W;86/103;AYCL-153P;AYCL-253P;CTCL-153P;CTRP-253P;DAL06P-C2;DDL06;DDMX1;DG6HD;DH6HD;DL6HD;DSE06-10Z;DSL06;DSL06-1LZ;DSM10;DUL06P-C2;DVCL-153P;DVCL-253P;DVRP-253P;DW6HD;DZ6HD;HQRA-PRO;HQRD-10D;HQRD-10NBD;HQRD-6ND;HQRD-HN |
| Dimmers | 6BRL;HQRD-PRO;HRST-PRO-N;IPE04-1L;IPL06;LECL-153P;MA-PRO;MACL-153M;MACL-LFQ;MRF2S-6ELV;MSCL-OP153M;NTCL-250;NTRP-250;NXFRD-UNV;PD-10NXD;PD-5NE;PD-6WCL;RCL-153PNL;RF9640-ND;RNL06-10Z;RRD-10D;RRD-6CL;RRD-6ND;RRD-H6BRL;RRD-PRO;RRST-PRO-N;S11268;SCL-153P |
| Dimmers | ;ST-PRO-N;STCL-153M;SUF7;TAL06P-C2;TGCL-153PH;TSL06;TSM10;TTCL-100H;VSUL06D;WSX-PDT-WH;WWRL50WH |
| Specifications | https://www.satco.com/catalog/product/specsheets/62-1800 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/62-1800_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/62-1800_Dimensional_Diagram.pdf |
| ANSI Base | Integrated |
| Beam Spread | 110 |
| Bulb Volts | 120V |
| Bulb Watts | 15 |
| CCT Selectable | Yes |
| Color Temp | Warm to Cool White |
| Connection | Hardwire |
| CRI | 93+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Forward Phase or Reverse Phase |
| DLC Approved | No |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | Disk Light |
| Has Driver | No |
| Has Emergency Battery | No |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 60W |
| Installation Notes | Keyhole Slots |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Finish | White |
| Lens Material | Acrylic |
| Lumens | 930L-1000L |
| Mounting Procedure | Ceiling |
| NSF Approved | No |
| Operating Frequency | 60Hz |
| Power Factor | 0.9 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Sloped Ceiling Compatible | Yes |
| Style | Contemporary |
| Surge Protection | Built-in surge protection - 2.5KV |
| Temperature (CCT) | 2700K/3000K/3500K/4000K/5000K |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
