From designer aesthetics to state of the art technology, BLINK's fixtures embody this concept entirely. The sleek, low-profile style features die-cast construction, and is CCT selectable, with five preset options from warm to natural light. BLINK Pro is the ideal fixture for installations where space is at a premium. The Pro series of fixtures are available in round and square, come in four finishes (white, black, bronze, and brushed nickel), and are offered in 5, 7 and 9 inch sizes, choose the best fit for your needs. The BLINK Pro series is perfect for corridors, closets, kitchens, bathrooms, bedrooms, even use outdoors as they are wet location certified for applications with a closed ceiling. All products feature a robust driver for enhanced surge protection, flicker free operation, smooth dimming and providing years of trouble-free operation.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=62-1725 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/62-1725_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/62-1725_Dimensional_Drawing.pdf |
| Video | https://youtu.be/QwoOpuyAKw8 |
| Collection | Blink Pro |
| Lighting Type | Fixtures |
| Fixture Type | Flush Mount |
| Fixture Shape | Square |
| Tariff Code | 9405.11.8020 |
| Warranty | 5 Years |
| Country of Origin | Thailand |
| CA Web Text | California T24 Listed |
| Flicker Free | No |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Wet |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| Beam Spread | 100° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Dimming Technology | 120V |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 100W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 1032-1150 |
| Voltage | 120 |
| Wattage | 13 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Die-Cast Aluminum |
| Style | Utility |
| Finish | Black |
| THD | <20% |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.9 |
| Surge Protection | Built-In Surge Protection - 2.5KV |
| Mounting Type | Ceiling |
| Sloped Ceiling Compatible | Yes |
| Dimensions | L: 9" x W: 9" x H: 0.67" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0888 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 12 |
| Case Length | 19.09" |
| Case Width | 11.81" |
| Case Height | 10.04" |
| Case Weight | 15.83 |
| Case Cubic Ft. | 1.3099 |
| Catalog Description | Blink Pro - 13W - 9in - LED Fixture - CCT Selectable - Square Shape - Black Finish - 120V |
| Description | BLINK 13W LED 9" SQ BLACK |
| Finish Family | Black |
| DLC Approved | No |
| ENERGY STAR | No |
| UNSPSC | 39112102 |
| Dimmable Function | 120V only |
| Image File Name | 62-1725.jpg |
| Installation Notes | Surface mount |
| Installation Notes | Compatible with 3"&4" J-box and pancake J-box with additional accessor |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 9.21 |
| Each Width In. | 1.81 |
| Each Height In. | 9.21 |
| Each Weight Lb. | 1.65 |
| Replaces | S21539 |
| Dimmers | 6672 |
| Dimmers | 6674 |
| Dimmers | 86/103 |
| Dimmers | ADTP703TU |
| Dimmers | AYCL-153P |
| Dimmers | AYCL-253P |
| Dimmers | CTCL-153P |
| Dimmers | CTRP-253P |
| Dimmers | DAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | DG6HD |
| Dimmers | DH6HD |
| Dimmers | DL6HD |
| Dimmers | DSE06-10Z |
| Dimmers | DSL06 |
| Dimmers | DSL06-1LZ |
| Dimmers | DSM10 |
| Dimmers | DUL06P-C2 |
| Dimmers | DVCL-153P |
| Dimmers | DVCL-253P |
| Dimmers | DVRP-253P |
| Dimmers | DW6HD |
| Dimmers | DZ6HD |
| Dimmers | HQRA-PRO |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-PRO |
| Dimmers | HRST-PRO-N |
| Dimmers | IPE04-1L |
| Dimmers | IPL06 |
| Dimmers | LECL-153P |
| Dimmers | MA-PRO |
| Dimmers | MACL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | NTCL-250 |
| Dimmers | NTRP-250 |
| Dimmers | PD-10NXD |
| Dimmers | PD-6WCL |
| Dimmers | RCL-153PNL |
| Dimmers | RF9640-ND |
| Dimmers | RHCL450PTC |
| Dimmers | RNL06-10Z |
| Dimmers | RRD-10D |
| Dimmers | RRD-6CL |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | RRD-PRO |
| Dimmers | RRST-PRO-N |
| Dimmers | S11268 |
| Dimmers | SAL06P |
| Dimmers | SCL-153P |
| Dimmers | ST-PRO-N |
| Dimmers | STCL-153M |
| Dimmers | SUF7 |
| Dimmers | TAL06P-C2 |
| Dimmers | TGCL-153PH |
| Dimmers | TSL06 |
| Dimmers | TSM10 |
| Dimmers | TTCL-100H |
| Dimmers | VSUL06D |
| Dimmers | 6672;6674;86/103;ADTP703TU;AYCL-153P;AYCL-253P;CTCL-153P;CTRP-253P;DAL06P-C2;DDMX1;DG6HD;DH6HD;DL6HD;DSE06-10Z;DSL06;DSL06-1LZ;DSM10;DUL06P-C2;DVCL-153P;DVCL-253P;DVRP-253P;DW6HD;DZ6HD;HQRA-PRO;HQRD-10D;HQRD-10NBD;HQRD-6ND;HQRD-HN6BRL;HQRD-PRO;HRST- |
| Voltage Text | AC Only |
| Accessories | 25-1725 |
| Accessories | 62-1725-EM |
| Closet Rated | No |
| Company | NUVO |
| Status | Active |
| Product Name | Blink Pro 13W 9in LED Fixture CCT Selectable Square |
