From designer aesthetics to state of the art technology, BLINK's fixtures embody this concept entirely. The sleek, low-profile style features die-cast construction, and is CCT selectable, with five preset options from warm to natural light. BLINK Pro 62-1714 is the ideal fixture for installations where space is at a premium. The BLINK Pro series is perfect for corridors, closets, kitchens, bathrooms, bedrooms, even use outdoors as they are wet location certified for applications with a closed ceiling. All products feature a robust driver for enhanced surge protection, flicker free operation, smooth dimming and providing years of trouble-free operation.
| Tariff Code | 9405.11.8020 |
|---|---|
| UNSPSC | 39112102 |
| Warranty | 5-Years |
| Country of Origin | Thailand |
| Additional Info | UGR - 26.13; SDCM - 464; Hi pot - DC-1550V; Edge-lit - Yes |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | California T24 Listed |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Dimension String | L:7.00" W:7.00" H:0.67" |
| ENERGY STAR | Yes |
| Finish | White |
| Fixture shape | Square |
| Indoor Outdoor | Indoor |
| Material | Die-Cast Aluminum |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Safety Listing | cETLus - Listed |
| Location Rating | Wet |
| SDS class | LED_Fixture |
| Technology | LED |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 11W |
| Length In. | 7 |
| Width In. | 7 |
| Height In. | 0.67 |
| Weight Lb. | 1.04 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923625367 |
| Each Quantity | 1 |
| Each Length In. | 7.2 |
| Each Width In. | 1.81 |
| Each Height In. | 7.2 |
| Each Weight Lb. | 1.16 |
| Each Cubic Ft. | 0.0543 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923625364 |
| Case Quantity | 12 |
| Case Length In. | 14.96 |
| Case Width In. | 11.81 |
| Case Height In. | 7.87 |
| Case Weight Lb. | 12.93 |
| Case Cubic Ft. | 0.8047 |
| Replaces | S21511;S29332;S29335;S29361;S9332;S9335;S9361 |
| Dimmers | 6672;6674;86/103;ADTP703TU;AYCL-153P;AYCL-253P;CTCL-153P;CTRP-253P;DAL06P-C2;DDMX1;DG6HD;DH6HD;DL6HD;DSE06-10Z;DSL06;DSL06-1LZ;DSM10;DUL06P-C2;DVCL-153P;DVCL-253P;DVRP-253P;DW6HD;DZ6HD;HQRA-PRO;HQRD-10D;HQRD-10NBD;HQRD-6ND;HQRD-HN6BRL;HQRD-PRO;HRST-P |
| Dimmers | RO-N;IPE04-1L;IPL06;LECL-153P;MA-PRO;MACL-153M;MACL-LFQ;MSCL-OP153M;NTCL-250;NTRP-250;PD-10NXD;PD-6WCL;RCL-153PNL;RF9640-ND;RHCL450PTC;RNL06-10Z;RRD-10D;RRD-6CL;RRD-6ND;RRD-H6BRL;RRD-PRO;RRST-PRO-N;S11268;SAL06P;SCL-153P;ST-PRO-N;STCL-153M;SUF7;TAL06 |
| Dimmers | P-C2;TGCL-153PH;TSL06;TSM10;TTCL-100H;VSUL06D |
| Accessories | 25-1714;62-1714-EM |
| Specifications | https://www.satco.com/catalog/product/specsheets/62-1714 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/62-1714_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/62-1714_Dimensional_Drawing.pdf |
| ANSI Base | Integrated |
| Beam Spread | 100 |
| CCT Selectable | Yes |
| Closet Rated | Yes |
| Color Temp | Warm White to Natural Light |
| CRI | 90+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | 120V only |
| DLC Approved | No |
| ES Unique ID | 3553083 |
| ES Category | Downlight Surface Mount |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | Flush Mount |
| Flicker Free | No |
| Has Emergency Battery | No |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 75W |
| Installation Notes | Surface mount; Compatible with 3"&4" J-box and pancake J-box with additional accessory |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Lumens | 940L-1000L |
| Mounting Procedure | Ceiling |
| NEC Compliance | Clothes Closet Certified - Reg: 410.16 (A)(3) and 410.16 (C)(5) |
| Operating Frequency | 60Hz |
| Power Factor | 0.9 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Sloped Ceiling Compatible | Yes |
| Style | Utility |
| Surge Protection | Built-in surge protection - 2.5KV |
| Temperature (CCT) | 2700K/3000K/3500K/4000K/5000K |
| THD | <20% |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
