Satco's 45 watt, 48 inch by 12 inch LED surface mount is a sleek lighting solution for commercial and residential applications. Illuminate kitchens, bathrooms, hallways, offices, and retail spaces with this low profile, dimmable surface mount in a white finish. Easy to install and durable, this surface mount delivers 50,000 hours of natural white light.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=62-1154 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/62-1154_Installation_Instructions.pdf |
| Collection | Blink Plus |
| Lighting Type | Fixtures |
| Fixture Type | BLINK Plus |
| Fixture Shape | Linear |
| Tariff Code | 9405.11.8020 |
| Warranty | 3 Years |
| Country of Origin | China |
| CA Web Text | California T24 Listed |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cETLus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | Integrated |
| CCT Selectable | No |
| Color of Light | Natural Light |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| Dimming Technology | 120V |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 200W |
| Base | Integrated |
| Shape | Integrated LED |
| Brightness (Lumens) | 4050 |
| Voltage | 120/277 |
| Wattage | 45 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 5000K |
| Material | Aluminum |
| Style | Utility |
| Finish | White |
| Operating Frequency | 50/60Hz |
| Operating Temp | -17C (+1.4F) to +45C (+113F) |
| Power Factor | 0.81 |
| Connection | Direct Wired |
| Mounting Type | Ceiling |
| Dimensions | L: 48" x W: 12" x H: 0.75" |
| Each Quantity | 1 |
| Each Cubic Ft. | 1.0209 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045900000000 |
| Case Quantity | 2 |
| Case Length | 49.29" |
| Case Width | 5.63" |
| Case Height | 15.24" |
| Case Weight | 24.8 |
| Case Cubic Ft. | 2.4474 |
| Catalog Description | 45W - 12 in. - x 48 in. - Surface Mount LED Fixture - 5000K - 80 CRI - Low Profile - White Finish - 120/277V |
| Description | 45W/LED/1X4/FLUSH/5K/WH |
| Finish Family | White |
| DLC Approved | No |
| ENERGY STAR | No |
| UNSPSC | 39112102 |
| Dimmable Function | 120V only |
| Image File Name | 62-1154.jpg |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 48.82 |
| Each Width In. | 2.48 |
| Each Height In. | 14.57 |
| Each Weight Lb. | 9.9 |
| Substitute | 62-1775 |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | RRD-PRO |
| Voltage Text | Dual Voltage |
| Company | NUVO |
| Status | Discontinued |
| Product Name | 45W LED Flat Panel. 1-ft. x 4-ft. 5000K 120-277V Dimmable |
