The Trax 62-102 LED wall sconce brings cool elegance with its contemporary design. The two, curved tracks spanning the length of the fixture bring drama and height extending above and below the fixture body. The curved frosted glass covers the integrated LED and pairs with the Brushed Nickel finish perfectly.
| Tariff Code | 9405.11.8010 |
|---|---|
| UNSPSC | 39111503 |
| Warranty | 3-Years |
| Country of Origin | China |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| ADA Compliant | Yes |
| CA Web Text | California T24 Listed |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Dimension String | W:7.00" H:20.00" E:3.50" |
| ENERGY STAR | No |
| Finish | Brushed Nickel |
| Indoor Outdoor | Indoor |
| Material | Steel |
| Operating Temp | -40C (-40F) to +90C (+194F) |
| Safety Listing | cETLus - Listed |
| Location Rating | Damp |
| SDS class | LED_Fixture |
| Technology | LED |
| UL Application | Wall |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 10W |
| Width In. | 7 |
| Height In. | 20 |
| Extends In. | 3.5 |
| Weight Lb. | 4.5 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923321023 |
| Each Quantity | 1 |
| Each Length In. | 21.25 |
| Each Width In. | 6.25 |
| Each Height In. | 8.75 |
| Each Weight Lb. | 4.6 |
| Each Cubic Ft. | 0.6725 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923321020 |
| Case Quantity | 4 |
| Case Length In. | 13.5 |
| Case Width In. | 18.25 |
| Case Height In. | 21.75 |
| Case Weight Lb. | 20.77 |
| Case Cubic Ft. | 3.1011 |
| Dimmers | CTRP-253P;NTRP-250;RRD-PRO;6674 |
| Specifications | https://www.satco.com/catalog/product/specsheets/62-102 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/62-102_Installation_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/62-102_Line_Drawing.pdf |
| Collection | Trax |
| ANSI Base | Integrated |
| CCT Selectable | No |
| Color Temp | Warm White |
| Connection | Hardwire |
| CRI | 80+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Forward Phase or Reverse Phase or Phase Selectable |
| DLC Approved | No |
| FCC Compliant | Yes |
| Finish Family | Nickel |
| Product Type | Sconce |
| Glass Finish | Frost |
| Has Emergency Battery | No |
| Avg Rated Hours | 30000 |
| Incandescent Equiv | 60W |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lumens | 800L |
| Mounting Width | 4.49 |
| Mounting Height | 9.6 |
| Mounting Procedure | Wall |
| Mounting String | L:9.60" W:4.49" H:0.69" |
| Number of Glass | 1 |
| Number of Shades | 1 |
| Operating Frequency | 60Hz |
| Power Factor | 0.98 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Shade Size String | L:13.00 W:7.00 H:1.09 |
| Style | Contemporary |
| Temperature (CCT) | 3000K |
| Up Down Installation | Universal |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 1 |
| bundle | 1 |
