3 Light - Track Lighting Kit - 12 Watt LED per Head - 3000K - 4 foot Track - 36 degree - Round shape with angle arm - White finish - H-Style
| Tariff Code | 9405.11.6020 |
|---|---|
| UNSPSC | 39111508 |
| Warranty | 3-Years |
| Country of Origin | China |
| Additional Info | Most Track Accessories and Parts are available and interchangeable between finishes |
| Bulb Included | Integrated |
| CA Prop 65 | Lead |
| CA Web Text | California T24 Listed |
| CA Regulations | California T24 2016 - 2025 JA8 Listed |
| Title 20 | Exempt |
| T24 Compliant | Yes |
| Dimension String | L:3.38" W:2.75" H:2.75" E:5.75" |
| ENERGY STAR | No |
| Finish | White |
| Fixture shape | Round |
| Indoor Outdoor | Indoor |
| Includes | (1) TR120 4 Foot Track, (1) TP154 Floating Power Feed, (3) TH423 Track Heads, All Required Mounting Hardware |
| Material | Stainless Steel |
| Safety Listing | cETLus - Listed |
| Location Rating | Dry |
| SDS class | LED_Fixture |
| Technology | LED |
| UL Application | Track |
| Volts | 120V |
| Voltage Text | AC Only |
| Watts | 36W |
| Length In. | 3.38 |
| Width In. | 2.75 |
| Height In. | 2.75 |
| Extends In. | 5.75 |
| Weight Lb. | 5.23 |
| IOT Enabled | No |
| Has Camera | No |
| Each UPC | 045923434235 |
| Each Quantity | 1 |
| Each Length In. | 5 |
| Each Width In. | 4.25 |
| Each Height In. | 48.31 |
| Each Weight Lb. | 5.5 |
| Each Cubic Ft. | 0.5941 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Case UPC | 10045923434232 |
| Case Quantity | 4 |
| Case Length In. | 48.98 |
| Case Width In. | 10.87 |
| Case Height In. | 8.27 |
| Case Weight Lb. | 22.26 |
| Case Cubic Ft. | 2.5481 |
| Dimmers | 6672;6674;66ELV;86/103;AYCL-153P;AYCL-253P;CTCL-153P;CTRP-253P;DAL06P-C2;DDMX1;DG6HD;DH6HD;DL6HD;DSE06-10Z;DSL06;DSL06-1LZ;DSM10;DUL06P-C2;DVCL-153P;DVCL-253P;DVRP-253P;DW6HD;DZ6HD;HQRA-PRO;HQRD-10D;HQRD-10NBD;HQRD-6ND;HQRD-HN6BRL;HQRD-PRO;HRST-PRO-N |
| Dimmers | ;IPE04-1L;IPL06;LECL-153P;MA-PRO;MACL-153M;MACL-LFQ;MRF2S-6ELV;MSCL-OP153M;NTCL-250;NTRP-250;PD-10NXD;PD-6WCL;RCL-153PNL;RF9640-ND;RH703PTUTC;RNL06-10Z;RRD-10D;RRD-6CL;RRD-6ND;RRD-H6BRL;RRD-PRO;RRST-PRO-N;S11268;SCL-153P;ST-PRO-N;STCL-153M;SUF7;TAL06 |
| Dimmers | P-C2;TGCL-153PH;TSL06;TSM10;TTCL-100H;VSUL06D;WWRL50WH |
| Accessories | TH423;TP144;TP146;TP148;TP150;TP152;TP154;TP167;TP169;TP171;TP240;TP243;TR118;TR120;TR122;TR124;TP256 |
| Specifications | https://www.satco.com/catalog/product/specsheets/TK423 |
| Instructions | https://assets.satco.com/media-prod/image/upload/Certs/TK423_Installation_Instructions.pdf |
| ANSI Base | Integrated |
| Beam Spread | 36 |
| Bulb Count | 3 |
| CCT Selectable | No |
| Color Temp | Warm White |
| CRI | 90+ |
| Dimmable | Yes-Dimmable |
| Dimmable Function | Reverse Phase or Phase Selectable; 120V only |
| DLC Approved | No |
| FCC Compliant | Yes |
| Finish Family | White |
| Product Type | Track Kit |
| Has Emergency Battery | No |
| Avg Rated Hours | 30000 |
| Incandescent Equiv | 225W |
| Lamp Base | Integrated |
| Lamp Shape | Integrated LED |
| Lumens | 3060L |
| Mounting Procedure | Ceiling |
| Operating Frequency | 60Hz |
| Power Factor | 0.94 |
| Replaceable Light Source | No |
| RoHS Compliant | Yes |
| Style | Contemporary |
| Temperature (CCT) | 3000K |
| Track Head Style | Angle Arm |
| Wattage Selectable | No |
| Order In Multiples Of | 1 |
| Shipping Tier | 2 |
| bundle | 1 |
