Illuminate your surroundings while maximizing energy efficiency and cost-effectiveness with SATCO NUVO's G4 and GY6.35 Halogen replacement lamps. Available in an array of shapes, bases, and finishes, these lamps are equipped with LED technology, ensuring substantial long-term savings. Engineered for low voltage operation and featuring 300-degree omni-directional lighting, these lamps are versatile for a multitude of applications, including accent lighting, chandeliers, landscape illumination, and displays. Choose between 3000K or 5000K CCT options to customize the lighting to your exact preferences.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S12122 |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S12122_Dimensional_Diagram.pdf |
| Lighting Type | Lamps |
| Fixture Type | Miniature |
| Tariff Code | 8539.52.0020 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | Lawful for Sale |
| Housing Color | White |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | cULus |
| Location Rating | Damp |
| Indoor Outdoor | Indoor |
| Amps | 0.490A |
| ANSI Base | G4 |
| Beam Spread | 300° |
| Candle Power | 35 |
| CCT Selectable | No |
| Color of Light | Soft White |
| Color Rendering Index (CRI) | 80+ |
| Dimmable | Yes |
| Avg Rated Hours | 25000 |
| Incandescent Equiv | 40W |
| Base | Bi Pin G4 |
| Lamp Filament | LED |
| Shape | T6 |
| Brightness (Lumens) | 430 |
| Voltage | 12 |
| Wattage | 4.5 |
| Color Temperature (Kelvin) | 3000K |
| Material | Ceramic / Polycarbonate (PC) |
| Finish | Clear |
| THD | 70% |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | 0.7 |
| Surge Protection | Built-In Surge Protection - 1.5KV |
| Three-Way | No |
| MOD | 0.73" |
| MOL | 1.81" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0067 |
| Pack Type | Carded |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 12 |
| Inner Length | 8.86" |
| Inner Width | 4.65" |
| Inner Height | 5.63" |
| Inner Weight | 0.83 |
| Inner Cubic Ft. | 0.1342 |
| Case UPC | 10045900000000 |
| Case Quantity | 48 |
| Case Length | 10.04" |
| Case Width | 9.45" |
| Case Height | 12.13" |
| Case Weight | 4.21 |
| Case Cubic Ft. | 0.666 |
| Catalog Description | 4.5 Watt Mini LED - G4 Base - 3000K - Clear Finish - 12 Volt |
| Description | 4.5W/LED/G4/CL/830/12V/1CD |
| DLC Approved | No |
| UNSPSC | 39101628 |
| Dimmable Function | Check the transformer/driver MFG for dimmer compatibility |
| Enclosure Rating | Enclosed Rated Lamp |
| Image File Name | S12122.jpg |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| SDS class | LED_Lamp |
| Technology | LED |
| Each Length In. | 3.27 |
| Each Width In. | 0.73 |
| Each Height In. | 4.84 |
| Each Weight Lb. | 0.06 |
| Company | SATCO |
| Status | Active |
| Product Name | 4.5W Mini LED G4 Base 3000K Clear 12V |
