SATCO NUVO's LED Retrofit Downlights are the easy way to convert traditional recessed lighting to LED. Offered in 4-inch and 5/6-inch models, these fixtures are sized for, and come ready with, an E26 base adapter for instant illumination when installed with existing cans. The stepped baffle design reduces glare and the fixture produces exceptional color rendering to enhance any environment from home to office.
| bundle | 1 |
|---|---|
| spec sheet | https://snap2satco.com/specifications/specsheet.php?sku=S11833R1 |
| INS URL | https://assets.satco.com/media-prod/image/upload/Certs/S11833R1_Instructions.pdf |
| Drawing | https://assets.satco.com/media-prod/image/upload/Certs/S11833R1_Dimensional_Diagram.pdf |
| Lighting Type | Fixtures |
| Fixture Type | Downlight Retrofit |
| Fixture Shape | Round |
| Tariff Code | 8539.52.0091 |
| Warranty | 5 Years |
| Country of Origin | China |
| CA Web Text | California T24 Listed |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| Certifications | Energy Star, cETLus |
| Location Rating | Wet |
| Indoor Outdoor | Indoor |
| CA Prop 65 | Lead |
| ANSI Base | E26 Adapter |
| Beam Spread | 90° |
| CCT Selectable | Yes |
| Color of Light | Warm White to Natural Light |
| Color Rendering Index (CRI) | 90+ |
| Dimmable | Yes |
| Avg Rated Hours | 50000 |
| Incandescent Equiv | 50W |
| Base | Medium Adapter |
| Shape | Integrated LED |
| Brightness (Lumens) | 600 |
| Voltage | 120 |
| Wattage | 6.7 |
| Bulbs | 1 |
| Bulb Included | Yes |
| Color Temperature (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Material | Steel |
| Style | Contemporary |
| Finish | Brushed Nickel |
| THD | <45% |
| Lens Finish | Frost |
| Lens Material | Plastic (PS) |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +40C (+104F) |
| Power Factor | >0.9 |
| Surge Protection | Built-In Surge Protection - 2.5KV |
| Air Tight | Yes |
| Can Size | 4" |
| Ceiling Aperture | 4.25" Cutout |
| Connection | Connector or Adapter |
| IC Rated | Yes |
| Mounting Type | Ceiling |
| Trim Color | Brushed Nickel |
| Diameter | 5.31" |
| Dimensions | H: 1.83" x DIA: 5.31" |
| Each Quantity | 1 |
| Each Cubic Ft. | 0.0346 |
| Pack Type | Box |
| Quantity In Pack | 1 |
| Inner UPC | 20045900000000 |
| Inner Quantity | 8 |
| Inner Length | 11.61" |
| Inner Width | 8.66" |
| Inner Height | 5.91" |
| Inner Weight | 3.77 |
| Inner Cubic Ft. | 0.3439 |
| Case UPC | 10045900000000 |
| Case Quantity | 16 |
| Case Length | 12.2" |
| Case Width | 9.25" |
| Case Height | 12.6" |
| Case Weight | 8.31 |
| Case Cubic Ft. | 0.8229 |
| Catalog Description | 6.7 Watt - LED Downlight Retrofit - 4 Inch - CCT Selectable - 120 Volts - Brushed Nickel Finish |
| Description | 6.7WLED/DLR/4/CCT-SEL/RD/BN |
| Finish Family | Brushed Nickel |
| DLC Approved | No |
| ENERGY STAR | Yes |
| UNSPSC | 39111515 |
| ES Unique ID | 3354716 |
| ES Category | Downlight Solid State Retrofit |
| Image File Name | S11833R1.jpg |
| SDS class | LED_Fixture |
| Technology | LED |
| Each Length In. | 5.51 |
| Each Width In. | 1.97 |
| Each Height In. | 5.51 |
| Each Weight Lb. | 0.43 |
| Replaces | S11833 |
| Dimmers | MA-PRO |
| Dimmers | RRD-PRO |
| Dimmers | HQRD-PRO |
| Dimmers | HQRA-PRO |
| Dimmers | ST-PRO-N |
| Dimmers | RRST-PRO-N |
| Dimmers | HRST-PRO-N |
| Dimmers | PD-5NE |
| Dimmers | CTRP-253P |
| Dimmers | DVRP-253P |
| Dimmers | NTRP-250 |
| Dimmers | SELV-300P |
| Dimmers | DSE06-10Z |
| Dimmers | MACL-153M |
| Dimmers | STCL-153M |
| Dimmers | MACL-LFQ |
| Dimmers | MSCL-OP153M |
| Dimmers | DVCL-153P |
| Dimmers | RCL-153PNL |
| Dimmers | AYCL-153P |
| Dimmers | SCL-153P |
| Dimmers | CTCL-153P |
| Dimmers | LECL-153P |
| Dimmers | TTCL-100H |
| Dimmers | DVCL-253P |
| Dimmers | AYCL-253P |
| Dimmers | NTCL-250 |
| Dimmers | TGCL-153PH |
| Dimmers | PD-6WCL |
| Dimmers | PD-10NXD |
| Dimmers | RRD-6ND |
| Dimmers | RRD-H6BRL |
| Dimmers | HQRD-6ND |
| Dimmers | HQRD-10D |
| Dimmers | HQRD-10NBD |
| Dimmers | HQRD-HN6BRL |
| Dimmers | HQRD-6CL |
| Dimmers | RRD-6CL |
| Dimmers | RNL06-10Z |
| Dimmers | TAL06P-C2 |
| Dimmers | DDMX1 |
| Dimmers | 86/103 |
| Dimmers | S11268 |
| Dimmers | 6672 |
| Dimmers | RRD-10D |
| Dimmers | 6674 |
| Dimmers | IPL06 |
| Dimmers | TSL06 |
| Dimmers | DSM10 |
| Dimmers | TSM10 |
| Dimmers | 66DF-10W |
| Dimmers | DSL06 |
| Dimmers | DDL06 |
| Dimmers | MAELV-600 |
| Dimmers | DW6HD |
| Dimmers | DH6HD |
| Dimmers | DG6HD |
| Dimmers | DL6HD |
| Dimmers | DZ6HD |
| Dimmers | DUL06P-C2 |
| Dimmers | VSUL06D |
| Dimmers | RHCL450PTC |
| Dimmers | RH703PTUTC |
| Dimmers | WWRL50WH |
| Dimmers | WSX-PDT-WH |
| Dimmers | RF9640-ND |
| Dimmers | DAL06P-C2 |
| Dimmers | NXFRD-UNV |
| Dimmers | 80/2699 |
| Dimmers | 80/2700 |
| Dimmers | 80/2701 |
| Dimmers | 80/2702 |
| Dimmers | 80/2703 |
| Dimmers | 80/2704 |
| Dimmers | PHPM-WBX-120 |
| Dimmers | ODMR0205 |
| Dimmers | MR42400PLS |
| Dimmers | MA-PRO;RRD-PRO;HQRD-PRO;HQRA-PRO;ST-PRO-N;RRST-PRO-N;HRST-PRO-N;PD-5NE;CTRP-253P;DVRP-253P;NTRP-250;SELV-300P;DSE06-10Z;MACL-153M;STCL-153M;MACL-LFQ;MSCL-OP153M;DVCL-153P;RCL-153PNL;AYCL-153P;SCL-153P;CTCL-153P;LECL-153P;TTCL-100H;DVCL-253P;AYCL-253 |
| Bulb Count | 1 |
| Voltage Text | AC Only |
| Accessories | 80-980 |
| Accessories | 80-981 |
| Accessories | S9000 |
| Accessories | S8999 |
| Accessories | 80-868 |
| Clearance Height | 3 |
| Company | SATCO |
| Status | Active |
| Product Name | 6.7W LED Downlight Retrofit 4" CCT Selectable 120V |
